CPT CLAT080WQ65 LCD

Specification

Model P/N:CLAT080WQ65
Brand:CPT
Diagonal Size:8.0"
Resolution:800(RGB)×1280, WXGA 188PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 52% NTSC
Backlight:4S5P WLED , 15K hours , No Driver
Signal Type:MIPI (4 data lanes) , 39 pins Connector
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:107.64(W)×172.224(H) mm
Bezel Opening:108.64(W)×173.22(H) mm
Treatment:Hard coating (3H)
Luminance:360 cd/m² (Typ.)
Outline(mm):119.6 × 205.4 × 4.9 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:-
Mass:TBD
Used for:Pad & Tablet
Refresh Rate:60Hz
Touchscreen:PCAP, I²C
Voltage Supply:1.8/3.3/16.5/-11V (Typ.)(VCI/VDD3/VGH/VGL)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
