CPT CLAN050WD61 6XM LCD

Specification

Model P/N:CLAN050WD61 6XM
Brand:CPT
Diagonal Size:5.0"
Resolution:720(RGB)×1280, WXGA 294PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:62.1(W)×110.4(H) mm
Bezel Opening:-
Treatment:With Polarizer
Luminance:0 cd/m²
Outline(mm):64.9 × 118.29 × 0.85 (H×V×D)
Response:30 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:FFS, Normally Black, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:On-Cell Touch
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C
Driver IC list:Built-in COG R61318
Transmissivity:4.2% (Typ.)(with APCF)
Glass Thickness:0.30+0.30 mm
