CPT CLAG080LQ17 BXX LCD

Specification

Model P/N:CLAG080LQ17 BXX
Brand:CPT
Diagonal Size:8.0"
Resolution:800(RGB)×480, WVGA 116PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 62% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:174(W)×104.4(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Outline(mm):184.5 × 117.3 × 1 (H×V×D)
Response:25 ms
Good View at:Symmetry
Work Mode:FFS, Normally Black, Transmissive
Mass:-
Used for:Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Max Ratings:Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C
Driver IC list:Suggest COG HX8249-A00DPD250-LT + HX8678-C00DPD250-LT
Transmissivity:3.8% (Typ.)
Glass Thickness:0.50+0.50 mm
