CPT CLAG045LA01 AX LCD

Specification

Model P/N:CLAG045LA01 AX 2
Brand:CPT
Diagonal Size:4.5"
Resolution:480(RGB)×854, FWVGA 219PPI
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:60/60/60/50 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:55.44(W)×98.637(H) mm
Bezel Opening:-
Outline Dim:58.64(H)×106.337(V) ×1(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 61% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.50+0.50 mm
Transmittance:5.3% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest OTM8009A, OTM8018B, NT35510, NT35512
