CPT CLAD014CB01 00XA LCD

Specification

Model P/N:CLAD014CB01 00XA 3
Brand:CPT
Diagonal Size:1.4"
Resolution:128(RGB)×128 125PPI
Brightness:0 cd/m²
Contrast Ratio:-
Viewing Angle:-
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Empty Cell)
Pixel Format:RGB Vertical Stripe
Active Area:25.4976(W)×26.496(H) mm
Bezel Opening:-
Response Time:-
Outline Size:27.7(W)×32.24(H) ×1(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 53% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone ，Wearable ，Square Display ，MP3 PMP
Driver IC:COGSuggest ILI9163C
Glass Depth:0.50+0.50 mm
Transmissivity:6.0% (Typ.)(with Polarizer)
