CPT CLAD013GA01 LCD

Specification

Model P/N:CLAD013GA01
Brand:CPT
Diagonal Size:1.35"
Resolution:240(RGB)×240 251PPI
Brightness:0 cd/m²
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Empty Cell)
Pixel Format:RGB Vertical Stripe
Active Area:23.4(W)×25.056(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:25.4(W)×29.906(H) ×1(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:262K 50% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Wearable ，Square Display
Driver IC:COGBuilt-in ILI93040L, ILI9341V
Glass Depth:0.50+0.50 mm
Transmissivity:3.6% (Typ.)(with APCF)
