CPT CLAC078WQ175TXX LCD

Specification

Model P/N:CLAC078WQ175TXX
Brand:CPT
Diagonal Size:7.8"
Resolution:400(RGB)×1280 171PPI
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:59.4(W)×190.08(H) mm
Bezel Opening:-
Outline Dim:64.8(H)×199.68(V) ×1.3(D) mm
Treatment:Antiglare (Haze 25%), Hard coating
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:HFFS, Normally Black, Transmissive
Support Color:16.7M 60% NTSC
Light Source:No B/L
Weight:-
Designed For:Automotive Display
Frame Rate:60Hz
Touch Panel:Without
Power Supply:1.8/3.3/5.5/-5.0/16.5/-11V (Typ.)(VDD3/VCI/VSP/VSN/VGH/VGL/)
Plate Thickness:0.50+0.50 mm
Transmittance:4.4% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest JD9366, ILI6136S
