CPT CLAC070WQ41 LCD

Specification

Model P/N:CLAC070WQ41
Brand:CPT
Diagonal Size:7.0"
Resolution:800(RGB)×1280, WXGA 215PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:94.2(W)×150.72(H) mm
Bezel Opening:-
Outline Dim:98.2(H)×159.62(V) ×0.9(D) mm
Treatment:Hard coating
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:FFS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Pad & Tablet
Frame Rate:60Hz
Touch Panel:Without
Interface Type:MIPI
Power Supply:1.8/3.3/6.0/-6.0V (Typ.)(VDD3/VCI/VSP/VSN)
Plate Thickness:0.45+0.45 mm
Transmittance:4.25% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest OTM1284A-C16
