CLAA070NB02CT CPT LCD panel replacement

Brand：CPT
Diagonal Size：7.0 inch
Pixel Format：1024(RGB)×600[WSVGA]
Active Area：153.6(H)×90(V) mm
Bezel Area：-
Luminance：300 cd/m2 (Typ.)
View Direction：6 o’clock
Viewing Angle：70/70/50/70 (Typ.)(CR≥10)
Support Color：262K
Weight：130g (Typ.)
Frame Rate：-
Model：CLAA070NB02CT
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 162.9(H)×102(V)×5.8(D)mm
Treatment：Antiglare
Contrast Ratio： 400:1 (Typ.) (TM)
Response Time：20 (Typ.)(Tr+Td)
Operating Mode： TN, Normally White, Transmissive
Light Source： WLED , W/O Driver
Designed For： MP4 PMP, MID UMPC,
Touch Panel：Embeded (4-wire Resistive)
Interface Type： 61 pinsRSDS (1 Channel), FPC
Power Supply： 3.3/9.6/18/-6V (Typ.)(VCC/AVDD/VDDG/VEEG)
Environment： Operating Temperature: -30 ~ 85 °C; Storage Temperature: -40 ~ 95 °C; Vibration Level: 2.9G (28.4 m/s2)
