AUO C146HAX01.1 LCD

Specification

Model P/N:C146HAX01.1
Brand:AUO
Diagonal Size:14.6"
Resolution:1920(RGB)×1080, FHD 150PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:88/88/88/88 (Typ.)(CR≥10)
Color Depth:16.7M 72% NTSC
Backlight:No B/L
Signal Type:LVDS (2 ch, 8-bit) , FPC 240 pins
Panel Type:LTPS TFT-LCD, CELL , FOG
Pixel Format:RGB Vertical Stripe
Active Area:323.136(W)×181.764(H) mm
Bezel Opening:-
Treatment:Hard coating
Luminance:0 cd/m²
Response:30 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:112g (Typ.)
Used for:Automotive Display
Refresh Rate:60Hz
Touchscreen:In-Cell Touch
Voltage Supply:3.3/6.6/-6.5/12/-10.5V (Typ.)(VDD1/VSP/VSN/VGH/VGL)
Max Ratings:Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C
Outline (mm):328.136×191.414×0.77 (H×V×D)
Driver IC list:Built-in COG HX83192C*2 or ILI6600*2
Transmissivity:4.7% (Typ.)(with Polarizer)
Glass Thickness:0.25+0.25 mm
