AUO C146HAA01.0 LCD

Specification

Model P/N:C146HAA01.0
Brand:AUO
Diagonal Size:14.6"
Resolution:1920(RGB)×1080, FHD 150PPI
Brightness:800 cd/m² (Min.)
Contrast Ratio:1300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:323.136(W)×181.764(H) mm
Bezel Opening:-
Response Time:25 (Max.)(Tr+Td)
Outline Size:339.34(W)×203.16(H) ×13.7(D) mm
Surface:Antiglare (Haze 3%), Hard coating (7H), Reflection 1.5% (Max.)
Best View on:Symmetry
Display Colors:16.7M
Lamp Type:11S4P WLED , 10K hours , Without Driver
Frequency:60Hz
Touch Screen:In-Cell Touch, I²C
Panel Weight:820g (Typ.)
Application:Outdoor High Brightness ，Automotive Display
Signal Interface:LVDS (2 ch, 8-bit) , 60 pins Connector
Input Voltage:3.3V (Typ.)
