AUO C070VAN02.4 LCD

Specification

Model P/N:C070VAN02.4
Brand:AUO
Diagonal Size:7.0"
Resolution:800×480(RGB), WVGA 133PPI
Contrast Ratio:1000 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥100)
Color Depth:16.7M 72% NTSC
Backlight:WLED , 10K hours , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) + SPI , FPC 50 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:157.35(W)×95.0(H) mm
Treatment:Antiglare
Luminance:1000 cd/m² (Typ.)
Response:9/11 (Typ.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:TBD
Used for:Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3/13/20/-8V (Typ.)(VDD/AVDD/VGH/VGL)
Max Ratings:Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²)
Outline (mm):167.3×109.2×11.88 (H×V×D)
