BOE BV067HPQ-L11-8Q00 LCD

Specification

Model P/N:BV067HPQ-L11-8Q00
Brand:BOE
Diagonal Size:6.7"
Resolution:720(RGB)×1650 268PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 69% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Full Cell, Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.148(W)×156.173(H) mm
Bezel Opening:-
Treatment:-
Luminance:0 cd/m²
Outline(mm):70.148 × 160.773 × 0.3 (H×V×D)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:ADS, Normally Black, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:60Hz
Touchscreen:In-Cell Touch
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Driver IC list:Suggest COG ILI9883A, ICNL9916, HX83108-A/B, NT36528, FT8057
Transmissivity:4.1% (Typ.)(with Polarizer)
Glass Thickness:0.15+0.15 mm
