BOE BV067BRQ-L10 LCD

Specification

Model P/N:BV067BRQ-L10
Brand:BOE
Diagonal Size:6.7"
Resolution:720(RGB)×1604 263PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:69.4008(W)×154.61(H) mm
Bezel Opening:-
Outline Dim:71.3812(H)×158.91(V) mm
Treatment:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Max.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 83% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:120Hz
Touch Panel:In-Cell Touch
Plate Thickness:-
Transmittance:7.72% (Typ.)(with APCF)
D-IC Detail:COG Suggest TD4160_B0, ILI9883C, NT36528, FT8 057S, ICNL9916C
