BOE BV066WBQ-L15 LCD

Specification

Model P/N:BV066WBQ-L15
Brand:BOE
Diagonal Size:6.6"
Resolution:720(RGB)×1600 266PPI
Contrast Ratio:1500 : 1 (Typ.) (TM)
Viewing Angle:75/75/75/75 (Typ.)(CR≥10)
Color Depth:16.7M 69% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.688(W)×152.64(H) mm
Bezel Opening:-
Treatment:-
Luminance:0 cd/m²
Response:26 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:HADS, Normally Black, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:In-Cell Touch
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C
Outline (mm):70.488×157.59 (H×V×D)
Driver IC list:Suggest COG ILI9881H
Transmissivity:4.65% (Typ.)
Glass Thickness:-
