BOE BV065WBQ-L12 LCD

Specification

Model P/N:BV065WBQ-L12
Brand:BOE
Diagonal Size:6.5"
Resolution:720(RGB)×1600 268PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×151.2(H) mm
Bezel Opening:-
Outline Dim:70.04(H)×156.35(V) mm
Treatment:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Max.)(Tr+Td)
Operating Mode:HADS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:In-Cell Touch
Plate Thickness:-
Transmittance:3.7% (Typ.)
D-IC Detail:COG Suggest NT36525B, ILI9881H, HX83102D, FT8006S-AA
