BOE BV057WFE-N30-1Q00 LCD

Specification

Model P/N:BV057WFE-N30-1Q00
Brand:BOE
Diagonal Size:5.7"
Resolution:720(RGB)×1520 294PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:62.1(W)×131.1(H) mm
Bezel Opening:-
Outline Dim:64.1(H)×136.1(V) ×1(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:26 (Max.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 72% NTSC
Light Source:No B/L
Weight:TBD
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.40+0.40 mm
Transmittance:5.16% (Typ.)(with APCF)
D-IC Detail:COG Suggest HX8394, ILI9881C, S6D7AA
