BOE BV050SQQ-N17-8201 LCD

Specification

Model P/N:BV050SQQ-N17-8201
Brand:BOE
Diagonal Size:5.0"
Resolution:540(RGB)×960, qHD 221PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:61.965(W)×110.16(H) mm
Bezel Opening:-
Outline Dim:64.87(H)×117.9(V) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:-
Transmittance:4.3% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest S6D78A0X04, HX8389-C, NT35517, OTM9605A, SC7702
