BOE BTL434880-W539L LCD

Specification

Model P/N:BTL434880-W539L
Brand:BOE
Diagonal Size:4.3"
Resolution:480(RGB)×800, WVGA 217PPI
Brightness:320 cd/m² (Typ.)
Contrast Ratio:410:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:56.16(W)×93.6(H) mm
Bezel Opening:-
Response Time:35 (Typ.)(Tr+Td)
Outline Size:61.96(W)×105.9(H) ×2.2(D) mm
Surface:-
Best View on:Symmetry
Display Colors:16.7M 76% NTSC
Lamp Type:8S1P WLED , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Signal Interface:MIPI (2 data lanes) , 51 pins FPC
Input Voltage:1.8/2.8V (Typ.)(IOVCC/VCI)
