Innolux BT133HG01 LCD

Specification

Model P/N:BT133HG01 1
Brand:Innolux
Diagonal Size:13.3"
Resolution:1280(RGB)×800, WXGA 113PPI
Brightness:220 cd/m² (Typ.)
Contrast Ratio:350:1 (Min.) (TM)
Viewing Angle:45/45/20/30 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:286.08(W)×178.8(H) mm
Bezel Opening:289.5(W)×182.2(H) mm
Response Time:25 (Typ.)(Tr+Td)
Outline Size:299(W)×195(H) ×5.5(D) mm
Surface:Hard coating (2H)
Best View on:6 o'clock
Display Colors:262K 45% NTSC
Lamp Type:1 pcs CCFL , 15K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:LVDS (1 ch, 6-bit) , 20 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Wedge (PCBA Bent, T≥5.2mm)
