BOE BF047WVG-100 LCD

Specification

Model P/N:BF047WVG-100
Brand:BOE
Diagonal Size:4.7"
Resolution:480(RGB)×800, WVGA 200PPI
Contrast Ratio:900 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:60.84(W)×101.4(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Response:35 (Max.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:AFFS, Normally Black, Transmissive
Mass:TBD
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Max Ratings:Storage Temp.: -40 ~ 85 °C Operating Temp.: -20 ~ 65 °C
Outline (mm):63.74×108.65×0.5 (H×V×D)
Driver IC list:Built-in COG HX8369-B
Transmissivity:5.7% (Typ.)(with APCF)
Glass Thickness:0.25+0.25 mm
