BOE BF039WVE-400 LCD

Specification

Model P/N:BF039WVE-400
Brand:BOE
Diagonal Size:3.9"
Resolution:480(RGB)×800, WVGA 235PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:51.84(W)×86.4(H) mm
Bezel Opening:-
Outline Dim:55.44(H)×93.9(V) ×0.4(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.20+0.20 mm
Transmittance:3.93% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest NT35510, NT35512, OTM8009A, OTM8018B
