BB050HDG-T40 BOE LCD panel replacement

Brand：BOE
Diagonal Size：5.0 inch
Pixel Format：720(RGB)×1280[WXGA]
Active Area：61.92(H)×110.08(V) mm
Bezel Area：-
Luminance：350 cd/m2 (Typ.)
View Direction：Symmetry
Viewing Angle：80/80/80/80 (Min.)
Support Color：16.7M 101% (CIE1931)
Weight：TBD
Frame Rate： 60Hz
Model：BB050HDG-T40
Type：AM-OLED , OLED
Configuration：RGB Vertical Stripe
Outline Dim.： 64.12(H)×116.72(V)mm
Treatment：Hard coating
Contrast Ratio： 17000:1 (Typ.) (TM)
Response Time：-
Operating Mode： –
Light Source： self, 10K hours
Designed For： Mobile Phone,
Touch Panel：Without
D-IC Detail： COG Built-in RM67120
Interface Type： MIPI (4 data lanes)
Power Supply： 2.8/1.8/6.0V (Typ.)(VCI/VDDIO/AVDD)
Environment： Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C
