AUO B173RTN01.2 LCD

Specification

Model P/N:B173RTN01.2 1
Brand:AUO
Diagonal Size:17.3"
Resolution:1600(RGB)×900, HD+ 106PPI
Contrast Ratio:400 : 1 (Typ.) (TM)
Viewing Angle:70/70/60/60 (Typ.)(CR≥10)
Color Depth:262K 60% NTSC
Backlight:WLED , 15K hours , With LED Driver
Signal Type:LVDS (2 ch, 6-bit) , Connector 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:382.08(W)×214.92(H) mm
Bezel Opening:385.48(W)×218.31(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:200 cd/m² (Typ.)
Response:8 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):398.1×232.8×5.8 (H×V×D)
Outline Shape:Wedge (PCBA Bent, T≥5.2mm)
