AUO B156HAN07.1 HW1A LCD

Specification

Model P/N:B156HAN07.1 HW1A
Brand:AUO
Diagonal Size:15.6"
Resolution:1920(RGB)×1080, FHD 141PPI
Brightness:300 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:344.16(W)×193.59(H) mm
Bezel Opening:-
Response Time:9 (Typ.)(Tr+Td), 7 (Typ.)(G to G), 3 (Typ.)(G to G)(OD)
Outline Size:359.5(W)×223.8(H) ×3.2(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:16.7M 72% NTSC
Lamp Type:WLED , 15K hours , With LED Driver
Frequency:144Hz
Touch Screen:Without
Application:Laptop ，Gaming
Signal Interface:eDP (4 Lanes) , eDP1.4 , 40 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Slim (PCBA Flat, T≤3.2mm)
