B141XN04 V2 AUO LCD panel replacement for Touchscreen

Manufacturer：AU Optronics
Model Name：B141XN04 V24 Compatible
Screen Size：14.1 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1024(RGB)×768 (XGA)
Arrangement：RGB Vertical Stripe
Active Area(mm)：285.696 × 214.272 (H×V)
Outline(mm)： 298.5 × 226.7× 5.8 (H×V×D)
Bezel Area(mm)：288.9 × 217.5 (H×V)
Treatment：Antiglare (Haze 25%), Hard coating (3H)
Luminance：150 cd/m2 (Typ.)
Contrast Ratio：250 : 1 (Min.) (TM)
Viewing Angle：40/40/10/30 (Min.)(CR≥10)
Response：20/30 (Typ.)(Tr/Td) ms
Good View at：6 o’clock
Work Mode：TN, Normally White, Transmissive
Color Depth：262K
Backlight：1 pcsCCFL, 10K hours, No Driver
Outline Shape： Wedge (PCBA Bent, Depth ≥5.2mm)
Used for： Laptop,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： LVDS (1 ch, 6-bit), Connector , 20 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 60 °COperating Temp.: 0 ~ 50 °C
