AUO B140XTN03.3 HW3A LCD

Specification

Model P/N:B140XTN03.3 HW3A
Brand:AUO
Diagonal Size:14.0"
Resolution:1366(RGB)×768, WXGA 112PPI
Brightness:220 cd/m² (Typ.)
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.399(W)×173.952(H) mm
Bezel Opening:-
Response Time:8 (Typ.)(Tr+Td)
Outline Size:320.4(W)×205.1(H) ×3.6(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:262K 45% NTSC
Lamp Type:WLED , 12K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Application:Laptop
Signal Interface:eDP (1 Lane) , 30 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:Flat (PCBA Flat, T3.4~4.0mm)
