AUO B140HAK02.0 LCD

Specification

Model P/N:B140HAK02.0
Brand:AUO
Diagonal Size:14.0"
Resolution:1920(RGB)×1080, FHD 157PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:309.14(W)×173.89(H) mm
Bezel Opening:-
Outline Dim:320.4(H)×205.1(V) mm
Treatment:-
Luminance:-
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.2M 45% NTSC
Light Source:WLED , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:On-Cell Touch
Interface Type:eDP (2 Lanes) Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
