AUO B140HAB03.2 LCD

Specification

Model P/N:B140HAB03.2
Brand:AUO
Diagonal Size:14.0"
Resolution:1920(RGB)×1080, FHD 157PPI
Brightness:220 cd/m² (Typ.)
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:309.14(W)×173.89(H) mm
Bezel Opening:-
Response Time:25 (Typ.)(Tr+Td)
Outline Size:317.3(W)×195.175(H) ×5.95(D) mm
Surface:Anti-Scatter, Hard coating (7H)
Best View on:Symmetry
Display Colors:262K 45% NTSC
Lamp Type:WLED , 15K hours , With LED Driver
Frequency:60Hz
Touch Screen:On-Cell Touch, I²C
Application:Laptop
Signal Interface:eDP (2 Lanes) , eDP1.2 , 40 pins Connector
Input Voltage:3.3V (Typ.)
Shape Style:-
