B139HAN03.2 AUO LCD panel replacement for Touchscreen

Manufacturer：AUO
Model Name：B139HAN03.2 (AUO323D)
Screen Size：14.0 inch
Screen Type：LCM,a-Si TFT-LCD
Pixel Number：1920(RGB)×1080 (FHD)
Arrangement：RGB Vertical Stripe
Active Area(mm)：309.37 × 174.02 (H×V)
Outline(mm)： 315.1 × 195.65× 2.4 (H×V×D)
Bezel Area(mm)：-
Treatment：Glare (Haze 0%), Hard coating (3H)
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：800 : 1 (Typ.) (TM)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Response：25 (Typ.)(Tr+Td) ms
Good View at：Symmetry
Work Mode：AHVA, Normally Black, Transmissive
Color Depth：16.2M 72%(CIE1931)
Backlight：WLED, 15K hours, With LED Driver
Outline Shape： Slim (PCBA Flat, Depth ≤3.2mm)
Used for： Laptop,
Refresh Rate：60Hz
Touchscreen：Without
Signal Type： eDP (2 Lanes), Connector , 30 pins
Voltage Supply：3.3V (Typ.)
Max. Ratings： Storage Temp.: -20 ~ 60 °COperating Temp.: 0 ~ 50 °C
