AUO B133XTN01.7 LCD

Specification

Model P/N:B133XTN01.7
Brand:AUO
Diagonal Size:13.3"
Resolution:1366(RGB)×768, WXGA 118PPI
Contrast Ratio:600:1 (Typ.) (TM)
Viewing Angle:70/70/60/60 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:293.42(W)×164.97(H) mm
Bezel Opening:-
Outline Dim:306.3(H)×195.2(V) ×3.2(D) mm
Treatment:Glare (Haze 0%)
Luminance:220 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:8 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 45% NTSC
Light Source:WLED , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:eDP (1 Lane) , eDP1.2 , 40 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Flat, T≤3.2mm)
