AUO B133HAN06.0 HW0A LCD

Specification

Model P/N:B133HAN06.0 HW0A
Brand:AUO
Diagonal Size:13.3"
Resolution:1920(RGB)×1080, FHD 166PPI
Contrast Ratio:600 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:262K 45% NTSC
Backlight:WLED , 15K hours , With LED Driver
Signal Type:eDP (2 Lanes) , eDP1.2 , Connector 30 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:293.76(W)×165.24(H) mm
Bezel Opening:-
Treatment:Antiglare
Luminance:220 cd/m² (Typ.)
Response:27 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Used for:Laptop
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):305.35×193.45×2.85 (H×V×D)
Outline Shape:Slim (PCBA Flat, T≤3.2mm)
