AUO B133HAN05.K LCD

Specification

Model P/N:B133HAN05.K
Brand:AUO
Diagonal Size:13.3"
Resolution:1920(RGB)×1080, FHD 166PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:293.76(W)×165.24(H) mm
Bezel Opening:-
Outline Dim:299.46(H)×176.98(V) ×4.4(D) mm
Treatment:-
Luminance:400 cd/m² (Typ.)
View Direction:Symmetry
Response Time:30 (Typ.)(Tr+Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 100% sRGB
Light Source:WLED , 15K hours , With LED Driver
Designed For:Laptop
Frame Rate:60Hz
Touch Panel:Without
Interface Type:eDP (2 Lanes) , eDP1.4 , 30 pins Connector
Power Supply:3.3V (Typ.)
Form Style:Slim (PCBA Bent, T≤3.0mm)
