B121EW03 V0 AUO LCD panel replacement for Touch Panel

Brand：AUO
Model：B121EW03 V0 (AUO3014)
Diagonal Size：12.1 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：1280(RGB)×800[WXGA]
Configuration：RGB Vertical Stripe
Active Area：261.12(H)×163.2(V) mm
Outline Dim.：275.8(H)×190.5(V)×5.2(D) mm
Bezel Area：264.12(H)×166.2(V) mm
Treatment：Antiglare (Haze 25%), Hard coating (3H)
Luminance：200 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
View Direction：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Viewing Angle：40/40/20/40 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：CCFL[1 pcs], W/O Driver
Form Style： Wedge (PCBA Bent, Depth ≥5.2mm)
Designed For： Laptop,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -40 ~ 65 °C
