B121EW01 V1 AUO LCD panel replacement

Brand：AU Optronics
Diagonal Size：12.1 inch
Pixel Format：1280(RGB)×800[WXGA]
Active Area：261.12(H)×163.2(V) mm
Luminance：200 cd/m2 (Typ.)
View Direction：6 o’clock
Viewing Angle：40/40/20/40 (Min.)(CR≥10)
Support Color：262K
Form Style：Wedge (PCBA Bent, Depth ≥5.2mm)
Frame Rate： 60Hz
Model：B121EW01 V11 Compatible
Type：a-Si TFT-LCD , LCM
Configuration：RGB Vertical Stripe
Outline Dim.： 275.8(H)×178(V)×5.5(D)mm
Contrast Ratio： 300:1 (Min.) (TM)
Response Time：10/15 (Typ.)(Tr/Td)
Operating Mode： TN, Normally White, Transmissive
Light Source： CCFL [1 pcs], W/O Driver
Designed For： Laptop,
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 6-bit), Connector
Power Supply： 3.3V (Typ.)
Environment： Operating Temperature: 0 ~ 50 °C; Storage Temperature: -20 ~ 60 °C
