B101EAN01.6 AUO LCD panel replacement for Pad & Tablet

Panel Brand：AUO
Panel Model：B101EAN01.6
Panel Size：10.1 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1280(RGB)×800 , WXGA
Pixel Format：RGB Vertical Stripe
Display Area：216.96(W)×135.6(H) mm
Bezel Opening：-
Outline Size：227.72(W)×147.8(H)×4.6(D) mm
Surface：Glare (Haze 0%), Hard coating (3H)
Brightness：400 cd/m2 (Typ.)
Contrast Ratio：800:1 (Typ.) (TM)
Viewing Angle：89/89/89/89 (Typ.)(CR≥10)
Display Mode：AHVA, Normally Black, Transmissive
Best View on：Symmetry
Response Time：30 (Typ.)(Tr+Td)
Display Colors：16.7M 50%(CIE1931)
Lamp Type：6S4PWLED, 15K hours, Without Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 140g (Max.)
Application： Pad & Tablet,
Signal Interface： LVDS (1 ch, 8-bit), 36 pins , Connector
Input Voltage：3.3V (Typ.)
Environment： Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
