AUO B070ATN01.0 CELL LCD

Specification

Model P/N:B070ATN01.0 CELL
Brand:AUO
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 169PPI
Contrast Ratio:-
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Color Depth:262K/16.2M 50% NTSC
Backlight:No B/L
Signal Type:LVDS
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×90(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Outline(mm):159.3 × 97.6 × 1.25 (H×V×D)
Response:8 (Typ.)(Tr+Td) ms
Good View at:12 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Pad & Tablet ，Industrial ，Digital Photo Frame ，Portable DVD Player
Refresh Rate:60Hz
Touchscreen:Without
Max Ratings:Storage Temp.: -30 ~ 60 °C Operating Temp.: -20 ~ 60 °C
Driver IC list:Suggest COG AU51008 + NT52003, OTA7159A + OTD9120A-C6, HX8282A + HX8696A
Transmissivity:4.9% (Typ.)(with Polarizer)
Glass Thickness:0.40+0.40 mm
