BOE AV128FHT-L12 LCD

Specification

Model P/N:AV128FHT-L12
Brand:BOE
Diagonal Size:12.8"
Resolution:1920(RGB)×1080, FHD 172PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:283.392(W)×159.408(H) mm
Bezel Opening:-
Outline Dim:321.4(H)×181(V) ×20.3(D) mm
Treatment:Antiglare (Haze 5%), Hard coating (3H), Antireflection
Luminance:800 cd/m² (Typ.)
View Direction:Symmetry
Response Time:30 (Max.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 75% NTSC
Light Source:WLED [6S6P] , 10K hours , W/O Driver
Weight:500g (Typ.)
Designed For:Outdoor High Brightness ，Automotive Display
Frame Rate:60Hz
Touch Panel:In-Cell Touch, SPI
Interface Type:LVDS (2 ch, 8-bit) , 60 pins Connector
Power Supply:3.3V (Typ.)
