BOE AV123Z7T-A19-D8P0 LCD

Specification

Model P/N:AV123Z7T-A19-D8P0
Brand:BOE
Diagonal Size:12.3"
Resolution:1920(RGB)×720 167PPI
Brightness:850 cd/m² (Typ.)
Contrast Ratio:1100:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, Assembly
Pixel Format:RGB Vertical Stripe
Active Area:292.032(W)×109.512(H) mm
Bezel Opening:-
Response Time:25 (Max.)(Tr+Td)
Outline Size:345.19(W)×149.1(H) ×27.93(D) mm
Surface:Anti Fingerprint + Antiglare, Hard coating (3H)
Best View on:Symmetry
Display Colors:16.7M 80% NTSC
Lamp Type:9S4P WLED , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:PCAP, I²C
Panel Weight:-
Application:Outdoor High Brightness ，Automotive Display
Signal Interface:LVDS (2 ch, 8-bit) , 60 pins Connector
Input Voltage:3.3V (Typ.)
