AV123Z7M-N11 BOE LCD panel replacement for Automotive Display

Panel Brand：BOE
Panel Model：AV123Z7M-N11
Panel Size：12.3 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1920(RGB)×720
Pixel Format：RGB Vertical Stripe
Display Area：292.032(W)×109.512(H) mm
Bezel Opening：295.03(W)×112.51(H) mm
Outline Size：307.9(W)×130.27(H) mm
Surface：-
Brightness：800 cd/m2 (Typ.)
Contrast Ratio：1000:1 (Typ.) (TM)
Viewing Angle：80/80/80/80 (Typ.)(CR≥10)
Display Mode：ADS, Normally Black, Transmissive
Best View on：Symmetry
Response Time：30 (Typ.)(Tr+Td)
Display Colors：16.7M 70%(CIE1931)
Lamp Type：9S4PWLED, 50K hours, Without Driver
Frequency： 60Hz
Touch Screen：Without
Panel Weight： 520±50g
Application： Automotive Display,
Signal Interface： LVDS (2 ch, 8-bit), 41 pins , Connector
Input Voltage：3.3/6.27/-12/18V (Typ.)(VCC/AVDD/VGH/VGL)
Environment： Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C
