BOE AT070WSM-NW1-3800(3G00) LCD

Specification

Model P/N:AT070WSM-NW1-3800(3G00)
Brand:BOE
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 170PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:80/80/60/70 (Typ.)(CR≥10)
Color Depth:262K/16.7M 50% NTSC
Backlight:3S10P WLED , 15K hours , No Driver
Signal Type:LVDS (1 ch, 6/8-bit) , FPC 40 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:154.214(W)×85.92(H) mm
Bezel Opening:157.22(W)×88.92(H) mm
Treatment:Antiglare
Luminance:500 cd/m² (Typ.)
Response:25 (Typ.)(Tr+Tf) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:150g (Max.)
Used for:Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3/9.6/18/-6V (Typ.)(VDD/AVDD/VGH/VGL)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):164.9×100×5.1 (H×V×D)
