AT050TN43 V.1 Innolux LCD panel replacement

Panel Brand：Chimei Innolux
Panel Model：AT050TN43 V.11 Compatible
Panel Size：5.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×480 , WVGA
Pixel Format：RGB Vertical Stripe
Display Area：108(W)×64.8(H) mm
Bezel Opening：110.6(W)×67.8(H) mm
Outline Size：120.7(W)×76.3(H)×3.3(D) mm
Surface：Antiglare
Brightness：350 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：70/70/50/70 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Display Colors：16.7M
Lamp Type：7S2PWLED, 20K hours, Without Driver
Frequency：60Hz
Touch Screen：-
Panel Weight： 60.0g (Typ.)
Application： Portable Navigation, Pocket TV, MP4 PMP, MID UMPC, Automotive Display, Gaming,
Signal Interface： Parallel RGB (1 ch, 8-bit), 40 pins, FPC
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
