Samsung AMS499QP89-0 LCD

Specification

Model P/N:AMS499QP89-0
Brand:Samsung
Diagonal Size:5.0"
Resolution:1080(RG/BG)×1920, FHD 360PPI
Contrast Ratio:3400:1 (Min.) (TM)
Viewing Angle:88/88/88/88 (Min.)(CR≥10)
Panel Type:AM-OLED, Assembly
Pixel Format:RG/BG PenTile
Active Area:62.1(W)×110.4(H) mm
Bezel Opening:-
Outline Dim:68.28(H)×143.26(V) ×1.87(D) mm
Treatment:Hard coating
Luminance:300 cd/m² (Typ.)
View Direction:Symmetry
Response Time:-
Operating Mode:-
Support Color:16.7M 100% NTSC
Light Source:self
Weight:-
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:PCAP, I²C
Interface Type:MIPI (4 data lanes) , 40 pins Connector
Power Supply:1.8/3.0/3.8V (Typ.)(IOVDD/VCI/VBAT)
