AMS395GB04 Samsung LCD panel replacement for Mobile Phone

Brand：SAMSUNG SMD
Model：AMS395GB04
Diagonal Size：4.0 inch
Type：AM-OLED， OLED
Pixel Format：360(RGB)×640[nHD]
Configuration：RGB Vertical Stripe
Active Area：49.14(H)×87.36(V) mm
Outline Dim.：53.76(H)×97.16(V) mm
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：1300:1 (Typ.) (TM)
View Direction：-
Response Time：-
Viewing Angle：-
Operating Mode：-
Support Color：16.7M 105%(CIE1931)
Light Source：self
Weight： 22.9g (Typ.)
Designed For： Mobile Phone,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 24 pinsMIPI (1 data lane)， Connector
Power Supply：3.7/1.8V (Typ.)(VPNL/VDDI)
Environment： Operating Temperature: -15 ~ 70 °C ; Storage Temperature: -40 ~ 85 °C
