AMS326PM01 Samsung LCD panel replacement

Panel Brand：SAMSUNG SMD
Panel Model：AMS326PM01
Panel Size：3.3 inch
Panel Type：AM-OLED, OLED
Resolution：854(RG/BG)×480 , FWVGA
Pixel Format：RG/BG PenTile
Display Area：72.16(W)×40.56(H) mm
Bezel Opening：-
Outline Size：80.56(W)×47.36(H)×0.86(D) mm
Surface：Glare (Haze 0%), Hard coating
Brightness：300 cd/m2 (Typ.)
Contrast Ratio：10000:1 (Typ.) (TM)
Viewing Angle：80/80/80/80 (Typ.)(CR≥200)
Display Mode：-
Best View on：Symmetry
Response Time：1 (Max.)(Tr+Td)
Display Colors：16.7M 106%(CIE1931)
Lamp Type：self
Frequency：60Hz
Touch Screen：Without
Driver IC：Built-in D53E6EA8805
Panel Weight： –
Application： Mobile Phone,
Signal Interface： Parallel RGB (1 ch, 8-bit) + SPI, 61 pins, FPC
Input Voltage：1.8/3.0/3.0V (Typ.)(VCCIO1/VCCIO2/VCI)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
