Samsung AMS300FW01 LCD

Specification

Model P/N:AMS300FW01
Brand:Samsung
Diagonal Size:3.0"
Resolution:240(RGB)×432, WQVGA 165PPI
Brightness:300 cd/m² (Typ.)
Contrast Ratio:10000:1 (Typ.) (TM)
Viewing Angle:-
Panel Type:AM-OLED, OLED , Full Module
Pixel Format:RGB Vertical Stripe
Active Area:36.96(W)×66.3(H) mm
Bezel Opening:-
Response Time:0.05 （Max.)(Tr+Td)
Outline Size:40.76(W)×74.44(H) ×0.88(D) mm
Surface:-
Best View on:-
Display Colors:262K 73% NTSC
Lamp Type:self , 20K hours
Frequency:50Hz
Touch Screen:Without
Panel Weight:8.00g (Typ.)
Application:Mobile Phone
Signal Interface:Parallel RGB (1 ch, 6-bit) + SPI , 49 pins FPC
Input Voltage:1.8/2.8V (VDD3/VCI)
Driver IC:COGBuilt-in S6E63D4
