AM-800600M3TNQW-01H-G AMPIRE LCD panel replacement for Touch Panel

Brand：AMPIRE
Model：AM-800600M3TNQW-01H-G
Diagonal Size：8.4 inch
Type：a-Si TFT-LCD, LCM
Pixel Format：800(RGB)×600[SVGA]
Configuration： RGB Vertical Stripe
Active Area：170.4(H)×127.8(V) mm
Outline Dim.：203(H)×145.5(V)×8.3(D) mm
Bezel Area：174.15(H)×131.2(V) mm
Treatment：-
Luminance：450 cd/m2 (Typ.)
Contrast Ratio： 600:1 (Typ.) (TM)
View Direction：-
Response Time：8 (Typ.)(Tr+Td)
Viewing Angle：75/75/60/70 (Typ.)(CR≥10)
Operating Mode：TN, Normally White, Transmissive
Support Color：262K
Light Source：WLED[12S4P], 50K hours, With LED Driver
Weight： 280g
Designed For： Industrial Application,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 20 pinsLVDS (1 ch, 6-bit), Connector
Power Supply：3.3V (Typ.)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
