AMPIRE AM-800600LTNQW-U0H LCD

Specification

Model P/N:AM-800600LTNQW-U0H
Brand:AMPIRE
Diagonal Size:10.4"
Resolution:800(RGB)×600, SVGA 96PPI
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:65/65/45/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:211.2(W)×158.4(H) mm
Bezel Opening:215.0(W)×162.0(H) mm
Outline Dim:236(H)×176.9(V) ×21.5(D) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:400 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:65K 50% NTSC
Light Source:WLED , With LED Driver
Weight:-
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:Without
Interface Type:UART , 8 pins Connector
Power Supply:4.6/26V (Min./Max.)(Vin)
