AMPIRE AM-800480RCTMQW-05H LCD

Specification

Model P/N:AM-800480RCTMQW-05H
Brand:AMPIRE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Contrast Ratio:400 : 1 (Typ.) (TM)
Viewing Angle:70/70/65/65 (Typ.)(CR≥10)
Color Depth:262K
Backlight:5S3P WLED , 50K hours , With LED Driver
Signal Type:Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:155.3(W)×94.3(H) mm
Treatment:-
Luminance:1000 cd/m² (Typ.)
Outline(mm):165 × 106 × 10.26 (H×V×D)
Response:5/11 (Typ.)(Tr/Td) ms
Good View at:-
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Industrial ，Outdoor High Brightness ，Automotive Display
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -35 ~ 85 °C Operating Temp.: -30 ~ 80 °C
