AM-800480R3TMQW-B2H AMPIRE LCD panel replacement for Automotive Display

Panel Brand：AMPIRE
Panel Model：AM-800480R3TMQW-B2H
Panel Size：7.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×480 , WVGA
Pixel Format：RGB Vertical Stripe
Display Area：152.4(W)×91.44(H) mm
Bezel Opening：155.3(W)×94.30(H) mm
Outline Size：165(W)×104.44(H)×7.06(D) mm
Surface：-
Brightness：500 cd/m2 (Typ.)
Contrast Ratio：400:1 (Typ.) (TM)
Viewing Angle：70/70/60/60 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：5/11 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：3S10PWLED, 40K hours, With LED Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： –
Application： Automotive Display,
Signal Interface： LVDS (1 ch, 6-bit), 40 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -30 ~ 80 °C
